Камнерезные пилы

Описание продукта

Tooth Pitch from sizes:

10mm to 50mm within these measurement.

Tooth profile or shape as follow:

Band saw blade in coils. Can be supplied in form of 100 meters length or longer.

Stone-cutting saws

HS steel strip for stone cutting saws is especially designed for the manufacture of diamond saw blades and is generally characterized by:

● A chemical composition which minimizes the risk of cracks in connection with brazing

● Good flatness and straightness

● square,smooth edges

Steel grade

HS SUBN-15

C=0.75%; Si=0.25%;Mn=0.35%;Ni=2.0%

Finishes

Surfaces:bright polished / blue polished/without polished / yellow polished

Edges: Sheared deburred

Round: One side round / Both side round

Square

Straightness: Deviation from straightness

max. 8mm/4m(0.315inch/13ft)

Max.0.25mm/m(0.010inch/3ft)

Standard sizes

Width		Thickness
Mm	Inch	Mm	Inch
180±0.7	7.09±0.028	3.00±0.056	0.118±0.0022
180±0.7	7.09±0.028	3.50±0.063	0.138±0.0025

These two standard sizes are continuously manufactured and the delivery security is good. Other sizes are obtainable on request.
